AUTOMATIC SIZING FOR EVERY SIZE OF MATTRESS
TOUCH PANEL SCREEN
GLUE BRIDGES: 2 KINDS, ONE OF THEM IS APPLIED CORNER AND CENTER GLUE ON FOAM AND FELT SIDES WITH HIGH SPEED AND DESIRED AMOUNT BY AUTOMATIC SIZING, AND THE OTHER IS APPLIED WITH 4 NOZZLES FROM THE CENTER ON THE FELTED MATTRESS
AUTOMATIC PRESSING SYSTEM: AFTER THE GLUE BRIDGE, THE MATTRESS GOES TO THE PRESS AND THEN BONDED WITH FELT, FOAM, AND QUILTED PANEL. PRESSING SYSTEM IS PNEUMATIC.
GLUING UNIT: ROBOTECH / NORDSON
SPECIALLY DESIGNED CONVEYOR SYSTEM WITH SILICON: SILICON BELT IN GLUE BRIDGES TO PREVENT GLUE CONTAMINATION AND STICKING
EDGE GLUEING: CORNER AND CENTER GLUE APPLICATION SYSTEM ON FOAM AND FELT SIDES WITH SPEED AND DESIRED AMOUNT
MATTRESS FLIPPING CONVEYOR: ONE FLIPPING CONVEYOR FOR TURNING THE MATTRESS: FLIPPER TURNS MATTRESS WITH PNEUMATIC SYSTEM AND WORKERS WILL TURN MATTRESS AUTOMATICALLY WITH A BUTTON WHEN ONE SIDE IS FINISHED.
CONVEYOR: ANTISTATIC PVC BELT
SPEED OF CONVEYOR: 30 METERS PER MINUTE

More information is available upon request.
E-mail us for price
Include our reference number
